proname ：YH-T7+E
Introduction
Weighing indicator YH-T7(+E) is widely applied in electronic platform scale, electronic floor scale and so on alike static weighing system equipped with 1~4 350Ω load cell.
Standard function
◆Single window with 2 inch height highlight LED display, the real“big eyes”
◆Peak value holding and average value function
◆Auto/Manual accumulate
◆Four grades battery indication, low power alarm and auto power off
◆High-Low limits alarm function, with HIGH-OK-LOW indications
◆Auto-sleep function
◆Preset tare
◆Precision auto zoom 10-magnification function
◆High precision A/D conversion with readability 1/30000
◆AC/DC power supply with built-in rechargeable 6V/4AH battery
◆RS232 interface with selectable baud rate
◆With scoreboard communication interface,20mA current loop way
Technical parameter
◆Precision grade:3 grades
◆Max division:3000
◆Input-signal range:-19mV～19mV
◆Conversion rate:more than 10 times/sec.
◆Nonlinear≤0.0015%
◆Load cell connection: able to connect with 1-4 350Ω load cell
◆Division:1/2/5/10/20/50(selectable)
◆Communication port:RS232(serial), 20mA current loop signal to scoreboard connection
◆Power supply:DC 5V; AC220V； 50、60Hz（-2%~+2%）
◆Operation temperature:-10 °C～40 °C
◆Storage/Transportation temperature:-25 °C～55 °C
Scoreboard Interface:
◆Signal output method: serial output, current loop signal
◆Baud rate:600
◆Distance of transmission:≤200m
Serial communication interface
◆RS232C
◆Baud rate:600/1200/2400/4800/9600 optional
◆Distance of transmission:≤30m
|
