MDB
Datasheet:MDB2 DatasheetFeatures:
Applications
DescriptionMDB is designed for truck and rail scales in high capacities with low proile. The design of loading through a ball is insensitive to side load. MDB is constructed of alloy steel and is hermeticallysealed to IP68 providing excellent protection against water and moisture attack. MDB can work well in corrosive and wash-down environments. |
| Product name : | CELTRON MDB Miniature Double-Ended Beam Load Cell |
| Product brand : | CELTRON |
| Warranty: | 12个月 |
| 额定载荷: | 10t,20t,25t,30t,40t,50t |
| 输出类型: | 模拟量毫伏值电压信号输出：mV/V |
| 额定输出: | 2.0mV/V |
| 非线性: | 0.030%R.O. |
| 零点回复（20分钟): | 0.03%R.O. |
| Hysteresis: | 0.03%R.O. |
| Repeatability: | 0.02%R.O. |
| Creep (20 min.): | 0.03%R.O. |
| Safe overload: | 150%R.O. |
| Ultimate overload: | 300%R.O. |
| Recommended excition voltage: | 10VDC |
| Maximum excitation: | 15VDC |
| Input impedance: | 770±5Ω |
| Output impedance: | 700±5Ω |
| Insulation resistance: | >5000MΩ |
| Material: | 合金钢镀镍 |
| Degree of protection: | IP67 |
| The lengh of the cable: | 13.5m |
CELTRON MDB Miniature Double-Ended Beam Load Cell
